Dc Inverter VRF plus Water Heater Solution Service Manual SERVICING
331
No. Part Name
GMV-R56/63/71/80T/Na-K GMVL-R56/63/71/80T/Na-K
Code Qty. Code Qty.
1
Tube Exit Plate
01382711
1
01382711
1
2 Body Fixed Plate
01332701
4
01332701
4
3
Front Side Plate
01302718
1
01302718
1
4
Left Side Plate
01302715
1
01302715
1
5 Base Plate
01222702
1
01222702
1
6
Rear Side Plate
01302714
1
01302714
1
7
Bottom Foam
52012711
1
52012711
1
8
Motor Gasket
76712711
3
76712711
3
9
Bolt
70212701
3
70212701
3
10 Motor Fixer
01702701
1
01702701
1
11 Fan Motor 15704102 1 15704102 1
12 Centrifugal Fan 10312705 1 10312705 1
13
Evaporator Connection
01072710
1
01072710
1
14
Cable-cross Loop
76513101
2
76513101
2
15 shunt
07228806
1
07228806
1
16
Water Tray
12412701
1
12412701
1
17
Screw
70140032
4
70140032
4
18 Electric Box Base Plate
01412721
1
01412721
1
19
Flow Guide Loop
10372701
1
10372701
1
20 Electric Box
20102701
1
20102701
1
21
Wire Clamp
71010102
4
71010102
4
22
Terminal Board T360B
42011222
1
42011222
1
23
Transformer
43110233
1
43110233
1
24 Electric Box Cover I
20102702
1
20102702
1
25
Electric Box Cover II
20102703
1
20102703
1
26 Main Board
30226316
1
30226316
1
27
Capacitor
33010010
1
33010010
1
28 Rubber plug
76712701
1
76712701
1
29
Evaporator
01004641
1
01004641
1
30 Evaporator Support
01072715
2
01072715
2
31
Nut with Washer M6
70310012
1
70310012
1
32 Bolt subassembly
70210051
1
70210051
1
33
Pipe Pump PJV-1415
43130324
1
43130324
1
34 Pump Gasket
76712702
3
76712702
3
35 Pump Support
01332001
1
01332001
1
36 Water Level Switch
45010201
1
45010201
1
37 Drainage hose Pump
05232721
1
05232721
1
38
Right Side Plate
01302716
1
01302716
1
39
Cable-cross Loop
76512702
1
76512702
1
40
Pump Cover
01252711
1
01252711
1
41 Bolt
70212701
3
70212701
3
42 Electronic Expansive Valve
0713411401
1
0713411401
1
