Dc Inverter VRF plus Water Heater Solution Service Manual SERVICING
335
No. Part Name
GMV-R90/112/125/140/Na-K GMVL-R90/112/125/140/Na-K
Code Qty. Code Qty.
1
Tube Exit Plate
01382711 1 01382711 1
2
Body Fixed Plate
01332701 4 01332701 4
3 Front Side Plate 01302713 1 01302713 1
4 Left Side Plate `01302711 1 01302711 1
5
Base Plate
01222702 1 01222702 1
6
Rear Side Plate
01302709 1 01302709 1
7 Bottom Foam 52012717 1 52012717 1
8
Motor Gasket
76712711 3 76712711 3
9 Bolt 70212701 3 70212701 3
10
Motor Fixer
01702701 1 01702701 1
11 Fan Motor 15704103 1 15704103 1
12 Centrifugal Fan 10310101 1 10310101 1
13
Evaporator Connection
01072733 1 01072733 1
14
Cable-cross Loop
76512702 2 76512702 2
15
shunt
07228804 1 07228804 1
16 Electronic Expansive Valve `07334102 1 07334102 1
17 Water Tray 12412701 1 12412701 1
18 Screw 70140032 4 70140032 4
19 Electric Box Base Plate 01412721 1 01412721 1
20 Flow Guide Loop 10372701 1 10372701 1
21 Electric Box 20102701 1 20102701 1
22 Wire Clamp 71010102 4 71010102 4
23 Terminal Board T360B 42011142 1 42011142 1
24 Transformer 43110233 1 43110233 1
25
Electric Box Cover I
20102702 1 20102702 1
26
Electric Box Cover II
20102703 1 20102703 1
27
Main Board
30226316 1 30226316 1
28
Capacitor
33010012 1 33010012 1
29 Rubber plug 76712701 1 76712701 1
30 Evaporator 01004640 1 01004640 1
31
Evaporator Support
01072708 2 01072708 2
32 Nut with Washer M6 70310012 1 70310012 1
33
Bolt subassembly
70210051 1 70210051 1
34
Pipe Pump PJV-1415
43130324 1 43130324 1
35
Pump Gasket
76712702 3 76712702 3
36
Pump Support
01332001 1 01332001 1
37
Water Level Switch
45010201 1 45010201 1
38
Drainage hose Pump
05232721 1 05232721 1
39
Right Side Plate
01302716 1 01302716 1
40 Cable-cross Loop 76512702 1 76512702 1
41 Pump Cover 01252711 1 01252711 1
42 Bolt 70212701 3 70212701 3
