Dc Inverter VRF plus Water Heater Solution Service Manual SERVICING
337
No. Part Name
GMV-R22T/NaA –K
GMV-R28T/NaA –K
GMVL-R22T/NaA –K
GMVL-R28T/NaA –K
Code Qty. Code Qty.
1
Display Board 30296309 1 30296308 1
2
Water Tray
20182703 1 20182703 1
3
Water Tray Foam for Fresh
Air Intaking
12312702 1 12312702 1
4
Water Tray Foam
12312703 1 12312703 1
5
Fan Fixer
76712709 1 76712709 1
6
Centifugal Fan
10312702 1 10312702 1
7
Motor FN11T-1
15704114 1 15704114 1
8
Evap Support
01844136 1 01844136 1
9
Evaporator Assy
01024194 1 01024194 1
10
Motor Support
01702702 1 01702702 1
11
Motor Gasket 76712705 1 76712705 1
12
Water Tray support 01332706 1 01332706 1
13
Front Side Plate
01302741
1
01302741
1
14
Body Fixer
01332705 1 01332705 1
15
Right Side Plate
01302743 1 01302743 1
16
Tube-exit plate
01382719 1 01382719 1
17
Cable-cross Loop
76515202 1 76515202 1
18
Noise Elimination Box
07444103 1 07444103 1
19
Electronic Expansion Valve
07334282 1 07334282 1
20
Expansion Valve Winding
4304000101 1 4304000101 1
21
Wire Clamp 71010103 1 71010103 1
22
Electric Box Assy 01394806
1
01394807
1
23
Terminal Board
42011106
1
42011106
1
24
Transformer 43110226 1 43110226 1
25
Capacitor CBB61
2.5uF/450VAC
33010026 1 33010026 1
26
Main PCB Z6G25C
30226199
1
30226198
1
27
Electric Box Cover
01424238
1
01424238
1
28
Base Plate 01222712
1
01222712
1
29
Cord Baffle Plate 01362701
1
01362701
1
30
Connecting Wire 40010232 1 40010232 1
31
Left Baffle Plate
01362703 1 01362703 1
32
Evap Connection
01072713 1 01072713 1
33
Water Level Switch Support
24212705
1
24212705
1
34
Right Baffle Plate
01362702
1
01362702
1
35
Water Level Switch
45012701
1
45012701
1
36
Pump Gasket 1
76712707
1
76712707
1
37
Pump Gasket 2
76712708
1
76712708
1
38
Pump Drainage
05232722
1
05232722
1
39
Pump Support
01332707
1
1332707
1
40
Water Pump PSB-7
43130320
1
43130320
1
41
Wire Clamp
71010105
1
71010105
1
