Dc Inverter VRF plus Water Heater Solution Service Manual SERVICING
345
No. Part Name
GMV(L)-R36G/NaB-K
；GMV(L)-R45G/NaB-K
Code Qty.
1 Wall-Mounting Frame 01252384 1
2 Rear Case
22202050
1
3 Evaporator Assy 01004629 1
4 Cross Flow Fan 10352005 1
5 Ring of Bearing 76712015 1
6 Drainage hose
05232411
1
7 Water Tray 20182030 1
8 Swing Louver 10512041 12
9 Swing Linkage 10582439 1
10 Front Case 200022955 1
11 Screw Cover 24252007 3
12 Filter 11122440 2
13 Remote Control Y612C 305160051 1
14 Decorate Piece 68012019 1
15 Receiver Board 30545552 1
16 Front Panel 20002292 1
17 Guide Louver 26112043 1
18 Guide Louver 26112042 1
19 Motor MP28EA 15212105 1
20 Right Motor Clamp 26112429 1
21 Motor FN22A 15012062 1
22 Electric Box Cover 22242017 1
23 Terminal Board T4B3A 42011233 1
24 Covering Plate 20102119 1
25 Electric Box 20102108 1
26 Main PCB Z6J15C 30226072 1
27 Transformer 48X26F 43110226 1
28 Wire Clamp 71010103 1
29 Rear Clamp 26112430 1
30 Signal Cable 400103953 1
