Dc Inverter VRF plus Water Heater Solution Service Manual PRODUCT
31
Model GMV(L)-R100T/Na-K GMV(L)-R112T/Na-K
Cooling Capacity
kW 10.0 11.2
Btu 34120 38210
Heating Capacity
kW 11.0 12.5
Btu 37540 42650
Air Flow Rate
m3/h 1860 1860
CFM 1095 1095
Sound Pressure Level (H/L) dB(A) 40/36 40/36
External Static Pressure Pa / /
Power Supply
220-240V-1Ph-50Hz 220-240V-1Ph-50Hz
Fan Motor
Output kW 0.06 0.06
Running
Current
A 0.59 0.59
Connecting
Pipes
Gas Pipe
mm Φ15.9 Φ15.9
inch
5/8＂ 5/8＂
Liquid Pipe
mm Φ9.52 Φ9.52
inch
3/8＂ 3/8＂
Connection Method Flare Connection Flare Connection
Drain Pipes
(External Dia. × Thickness)
mm
Φ30×1.5 Φ30×1.5
Unit Dimensions
(W×D×H)
mm
Main body：840×840×320
Panel：950×950×60
Package Dimensions
(W×D×H)
mm
Main body：960×960×394
Panel：1040×1025×115
Net Weight
(Main body/Panel)
kg 38/6.5
Gross Weight
(Main body/Panel)
kg 46/10
Notes:
① Refer to the product nameplate for parameters and specification of the unit;
② The model with GMVL code is cooling only unit; while the model with GMV code is heat pump unit; the
cooling only units does not have any parameters of performing heating;
③ The sound level is tested under circumstance of semi-anechoic chamber; the value of noise could be a
little higher in actual operation.
