Dc Inverter VRF plus Water Heater Solution Service Manual SERVICING
353
No. Part Name
GMV(L)-R36G/NaC-K
；GMV(L)-R45G/NaC-K
Code Qty.
1 Wall Mounting Frame 01252384 1
2 Rear Case Sub-Assy 22202051 1
3 Evaporator Assy 01004629 1
4 Cross Flow Fan 10352005 1
5 Ring of Bearing 76712015 1
6 Drain Pipe 0523001401 1
7 Water Tray 201820302 1
8 Air Louver 10512041 12
9 Swing Lever 10582439 1
10 Front Case 200025253 1
11 Screw Cap 24252007 3
12 Filter 11122440 2
13 Remote Control Y512 305125063 1
14 Display Board 30545558 1
15 Front Panel 20002524 1
16 Lower Guide Louver 26112043 1
17 Upper Guide Louver 26112042 1
18 Stepping Motor 15212105 1
19 Motor Right Clamp 26112429 1
20 Motor FN22G 150120623 1
21 Electric Box Cover 22242017 1
22 4-bit Terminal Board 42011233 1
23 Covering Plate 20102119 1
24 Electric Box 20102108 1
25 Main PCB Z6J251B 30226075 1
26 Transformer 43110226 1
27 Fixed Clamp 71010103 1
28 Rear Clamp 26112430 1
29
Connecting Wire（communicate)
400103953 1
