Dc Inverter VRF plus Water Heater Solution Service Manual SERVICING
358
No. Part Name
GMV(L)-R71Zd/Na-K
Code Qty.
1 Left Decoration Plate 261124172 1
2 Shaft of Louver I 10512025 2
3 Swing Louver Fixer sub-assy 013324232 1
4 Louver Support 24212020 3
5 Louver Fixer 24222016 2
6 Louver 105124042 1
7 Shaft of Louver II 10512026 2
8 Right Decoration Plate 261124212 1
9 Left Swing Motor Fixer 26152007 1
10 Front Panel 01532414 1
11 Display Box 20102138 1
12 Display Board 5T52 30545654 1
13 Front Panel 01544106 1
14 Right Swing Motor Fixer 26152008 1
15 Step Motor MP35CA 15212402 2
16 Motor Clamp 26112026 4
17 Water Tray 01272412 1
18 Auxiliary Water Tray 01272413 1
19 Pipe Clip 70812001 1
20 Drainage hose 05235433 1
21 Handle 26232001 4
22 Right Side Foam sub-assy 12312407 1
23 Right Fixing Palte 01332404 1
24 Support of Motor Bearing 01792408 2
25 Fixer of Motor Support 01792409 1
26 Right Decoration Panel 26112033 1
27 Pipe Clamp 01072424 1
28 Electric Box 01402407 1
29 Wire Base 24253001 1
30 Wire Clamp 24253002 1
31
Terminal Board 42011159 1
32 Fuse 5A 250VAC 46010013 1
33 Main PCB Z6935 30226903 1
34 Ring of Bearing 76512404 2
35 Fan Bearing 76512210 2
36 Transformer 57X25C 43110237 1
37 Cover of Electric Box 01412408 1
38 Centrifugal Fan 10312401 4
39 Rotary Axis 73012401 2
40 Capacitor CBB61 3uF/450 33010027 1
41 Motor FN100A 15012406 1
42 Motor Fixer 01722409 1
43 Motor Clamp 01702405 2
44 Axes Connector 73012403 2
