DTMF MEMORY ENCODER
D Automatic transmission (DTMF memory)
qPush and hold [TONE•DTMF] for 1 sec. to enter DTMF set
mode.
wRotate [DIAL] to select
“DTMF MEMORY,” then push
[MAIN•BAND] to enter DTMF memory screen.
eRotate [DIAL] to select the desired DTMF memory channel
to be transmitted then push [BACK](V/MHz•SCAN)
(Right
band’s).
• Returns to DTMF set mode screen.
rRotate [DIAL] to select “AUTO TX,” then push
[MAIN•BAND].
tRotate [DIAL] to select “ON,” then push [MAIN•BAND].
• “
☎
” appears.
yPush [BACK](V/MHz•SCAN) (Right band’s) to exit from
DTMF set mode.
u
Push [PTT] to transmit the selected DTMF memory content.
iTo cancel the DTMF tone sequence automatic transmis-
sion, select “OFF” in step t.
•When the DTMF encoder is turned ON continuously, each push
of the PTT transmits the previously selected DTMF tone se-
quence.
z Push [FUNC] then [
LOW
6(DTMF)] to turn the
DTMF memory encoder ON.
•“
☎
” appears.
x Push [PTT] to transmit the previously selected
DTMF memory.
c Push [FUNC] then [
SET
B(D-OFF)] to cancel the
DTMF memory encoder.
• When the DTMF encoder is turned ON continuously,
each push of the PTT transmits the previously se-
lected DTMF tone sequence.
DTMF
■ Transmitting a DTMF tone sequence
