105
14
MENU SCREEN OPERATION
■ SCAN items
DD
Scan timer
Selects scan resume timer from T-15 (default), T-10, T-5 and
P-2.
•T-15/10/5 : Scan pauses for 15/10/5 sec., then resumes.
• P-2 : Pause on a signal until signal disappears,
then resumes 2 sec. after the signal disap-
pears.
DD
Program skip scan
Sets programmed skip scan setting from ON (default) and
OFF for full scan or programmed scan operation.
DD
Bank link scan
Sets the memory bank link function ON and OFF (default). The
link function provides continuous bank scan, scanning all con-
tents in the selected banks during bank scan.
• Bank link setting
q Enter MENU screen via function guide.
➥ Push [F•] to display function guide.
➥ Push [MENU](V/MHz•SCAN)
(Right band’s) to enter
MENU screen.
w Rotate [DIAL] to select “SCAN,” then push [MAIN•BAND].
e Rotate [DIAL] to select “BANK LINK,” then push
[MAIN•BAND] to enter bank setting.
r Rotate [DIAL] to select the desired bank initial, then push
[MAIN•BAND].
t Rotate [DIAL] to turn ON
(default) and OFF the link setting,
then push [MAIN•BAND].
y Rotate [DIAL] to select next bank and repeat steps r to
t, or push [BACK](V/MHz•SCAN)
(Right band’s) three
times to exit scan set mode.
