GPS/GPS-A OPERATION
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
■ GPS-A operation
DD
GPS-A function
Set the following for activate the GPS-A function.
qSelect the DV mode operation (p. 39)
wSet the GPS function ON. (p. 125)
eSelect the DV data transmission to AUTO. (p. 127)
rSelect the GPS transmission selection to GPS-A. (p. 127)
tSet the GPS auto transmission interval. (p. 128)
ySet the GPS-A set items. (p. 113)
DD
GPS-A code details
While in GPS-A operation, following codes are transmitted to
your connecting PC. GPS-A code is based on APRS
®
code.
(APRS
®
: Automatic Position Reporting System)
JA3YUA-1>GPS-A,IC-2820:/002338h3437.38N/13534.24E>000/000/I am here! Can you watch me?
Your own call sign
Unproto address
Time stamp
Time stamp h; H.M.S (Hour/Minute/Second)
z; D.H.M (Day/Hour/Minute)
Latitude
Longitude
Data extension
Comment
GPS-A symbol (Car)
