MENU SCREEN OPERATION
■ SOUND items
DD
Key-touch beep
The key-touch beep can be turned OFF for silent operation.
(default: ON)
DD
Beep level
Adjusts the key-touch beep tone level to the desired level
from 9 levels.
•1
(Minimum level) to 9 (Maximum level) (default: 9)
The key-touch beep function must be set to ON to have a
beep tone.
DD
Scope AF output
Select the audio output function capability during sweep with
band scope function.
•ON: The received audio sounds during sweep.
(default)
• OFF : No audio sounds during sweep.
DD
Sub band mute
Turns the sub band mute function capability ON and OFF
(de-
fault)
.
DD
Sub band beep
Turns the sub band busy beep function capability ON and
OFF
(default).
DD
Standby Beep
☞ Available only when the
UT-123 is installed.
Turns the beep emission capability ON and OFF when the
communicating station finishes transmitting or the receive sig-
nal disappears while in the DV mode operation.
(default: ON)
