108
14
MENU SCREEN OPERATION
1
2
3
4
5
6
7
8
9
10
11
14
13
14
15
16
17
18
19
DD
Opening logo
The opening logo indication (Icom logo and transceiver name)
that is displayed at power ON can be skipped, if desired.
• ON : Opening logo is displayed at power ON.
(default)
• OFF : Opening logo indication is skipped.
DD
Opening call sign
☞ Available only when the
UT-123 is installed.
The set your own call sign, programmed in my call sign, can
be displayed at power ON.
(default: OFF)
DD
Scan name
The programmed scan or bank name is displayed during the
scan type selection.
•ON: The programmed scan or bank name is dis-
played.
(default)
• OFF : The programmed scan or bank name is not dis-
played.
DD
RX Call Sign Display
☞ Available only when the
UT-123 is installed.
When a call is received, the calling station call sign can be in-
dicated automatically.
(default: AUTO)
DD
TX Call Sign Display
☞ Available only when the
UT-123 is installed.
Selects call sign display function from YOUR, MY and OFF.
When this setting is set to YOUR or MY, the transceiver auto-
matically indicates the set station or your own call sign at DV
mode transmission.
(default: YOUR)
DD
RX message Display
☞ Available only when the
UT-123 is installed.
Sets auto received message display function AUTO and OFF.
When this setting is set to AUTO, the transceiver automati-
cally displays and scrolls the received message.
(default: AUTO)
