111
14
MENU SCREEN OPERATION
■ PACKET items
DD
Packet BPS
Selects the data transmission speed for packet operation
from 1200 bps
(default) and 9600 bps.
DD
Packet operation band
Selects the packet operation band from main, right and left.
• MAIN : The main band is used for packet op-
eration.
(default)
•L(Left)/R (Right) : The selected left or right band can
only be operated for packet.
■ GPS SET MODE items
DD
GPS SPEED
Selects the data transmission speed for packet operation
from 4800 bps
(default) and 9600 bps.
DD
Display units
Selects display units for distance and elevation from “m” or
“ft/ml.”
(default : USA/General versions; ft/ml, Other versions; m)
DD
Compass type
Selects compass indication type from “ARROWHEAD” (de-
fault), “NORTH REF” and “SOUTH REF.”
DD
UTC offset
Sets time difference from UTC (Universal Time Coordinated)
within –12:00 to +12:00 range in 5 min. steps.
(default: 0:00)
DD
GPS datum
Selects the GPS datum (country/area code) from 0 (default) to
224.
If wrong GPS datum
(country/area code) is set, the position
measuring accuracy may be poor.
