76
8
SCAN OPERATION
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
■ Scan edges programming
Scan edges can be programmed in the same manner as
memory channels. Scan edges are programmed into scan
edges, 0A/0B to 9A/9B, in memory channels.
qSet the edge frequency of the desired frequency range in
VFO mode:
➥ Set the frequency using the desired band’s [DIAL].
➥ Set other data
(e.g. repeater settings, etc.) if desired.
wPush the same band’s [M/CALL•MW] for 1 sec.
•“X” indicator and channel number blink.
eRotate the same band’s [DIAL] to select one of scan edge
channel, 0A to 9A.
rPush and hold [S.MW](M/CALL•MW)
(Left band’s) for 1 sec.
to program.
•3 beeps sound and VFO is automatically selected.
• Scan edge 0B to 9B is automatically selected when continuing to
push the [M/CALL•MW] after programming.
tTo program a frequency for the other pair of scan edges,
0B to 9B, repeat steps q and r.
• If the same frequency is programmed into a pair of scan edges,
programmed scan will not function.
[EXAMPLE]: Programming 145.300 MHz into scan edges 1A.
Push to select VFO mode. Rotate for setting frequency, etc. Push and hold for 1 sec.
Rotate Push and hold (Left band’s) for 1 sec. and continue to push
➠
Beep
“
V/MHz
SCAN
M/CALL
MW
M/CALL
MW
M
A
I
N
B
A
N
D
Beep
Beep
Beep
“
“
“
“
“
Beep
Beep
“
“
“
“
“
S.MW
M
A
I
N
B
A
N
D
