MENU SCREEN OPERATION
1
2
3
4
5
6
7
8
9
10
11
14
13
14
15
16
17
18
19
DD
Repeater call sign auto write
When accessing a repeater with a call sign that is different
than the one programmed in your radio, the repeater call sign
can be set into “RPT1” and or “RPT2” automatically by read-
ing the repeater’s transmission.
(default: OFF)
The transceiver sets the received repeater call sign for op-
eration. Therefore, when a different call sign is set for op-
eration, the previously set repeater call sign will be lost.
DD
DV auto detect
When a signal other than DV mode is received during DV
mode operation, the transceiver has the capability of auto-
matic FM mode selection.
• OFF : Operating mode is fixed in DV.
(default)
• ON : The transceiver automatically selects FM
mode for temporary operation.
DD
Call sign edit record
Selects the call sign programming when the call sign is edited
or corrected with the pre-programmed call sign via call sign
set screen.
• SELECT : The edited or corrected call sign is pro-
grammed
(over written) into the selected call
sign memory.
• AUTO: The edited or corrected call sign is pro-
grammed into a blank channel automatically.
(default)
DD
EMR communication
Turns the EMR communication mode ON and OFF (default).
DD
Break-in communication
Turns the break-in communication mode ON and OFF (de-
fault).
