PANEL DESCRIPTION
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
➥ During DV* (Digital) mode operation:
●
●
“DSQL” appears while the digital call sign squelch
function is in use.
(p. 91)
●
●
“CSQL” appears while the digital code squelch func-
tion is in use.
(p. 91)
➥ “” appears with the “TSQL,” “DTCS,” “DSQL”* or “C
SQL”* indicator while the pocket beep function is in use.
(pgs. 86, 91)
*Available only when the optional UT-123 is installed.
tEMR MODE INDICATOR (p. 56)
Appears when the EMR mode* operation is in use.
*Available only when the optional UT-123 is installed.
yGPS INDICATOR (p. 126)
Appears while GPS function* is in use.
*Available only when the optional UT-123 is installed.
uSUB BAND REMOTE CONTROL INDICATOR (p. 96)
Appears when the sub band remote control function is in
use.
iBREAK-IN INDICATOR
(p. 51)
Appears when the break-in* operation is in use.
*Available only when the optional UT-123 is installed.
oAUTO POWER OFF INDICATOR (p. 118)
Appears when the auto power OFF function is in use.
!0KEY LOCK INDICATOR
(p. 19)
Appears when the key lock function is activated.
!1DTMF INDICATOR
(p. 83)
Appears while automatic DTMF transmission is in use.
!2FREQUENCY READOUT
Shows the operating frequency, set mode contents, etc.
• Frequency decimal point blinks while scanning. (p. 75)
!3PRIORITY INDICATOR (p. 81)
Appears while priority watch is activated, blinks while pri-
ority watch is paused.
!4MEMORY CHANNEL NUMBER INDICATORS
➥ Shows the selected memory channel number.
(p. 61)
➥ Shows the selected bank initial. (p. 64)
➥ “C” appears when the call channel is selected. (p. 72)
!5SKIP INDICATOR (p. 79)
➥ “≈” appears when the displayed memory channel is
specified as a skip channel.
➥ “
P
≈” appears when the displayed frequency is specified
as a program skip frequency.
!6MEMORY INDICATOR
(p. 61)
Appears when memory mode is selected.
!7WEATHER ALERT INDICATOR
(p. 123)
“WX” appears when the weather alert function is in use.
*Available with the USA version only.
!8S/RF INDICATORS
➥ Shows the relative signal strength while receiving sig-
nals.
(p. 20)
➥ Shows the output power level while transmitting. (p. 21)
