MENU SCREEN OPERATION
■ GPS-A SET MODE items
DD
Unproto address
Sets up to 56-character unproto address.
qPush [MAIN•BAND] to enter programming condition.
wRotate [DIAL] to select the desired character.
• Push [Aa](TONE•DTMF) to select the character group from cap-
ital letters or lower case letters.
• Push [1/](M/CALL•MW) (Right band’s) to select the character
group from numbers or symbols.
• Push [>](M/CALL•MW) (Left band’s) or [<](V/MHz•SCAN) (Left
band’s) to move the cursor right or left, respectively.
• Push [CLR](DUP/MONI) to clear the selected character.
• Push and hold [CLR](DUP/MONI) for 1 sec. to clear all charac-
ters after the selected character.
eRepeat steps w until the desired address is programmed.
rPush [MAIN•BAND] to set the programmed address.
tPush [BACK](V/MHz•SCAN)
(Right band’s) to return to the
GPS-A set mode screen.
DD
Data extension
Sets the data extension capability from “COURSE/SPEED”
and OFF
(default).
The transceiver’s course and speed information is addition-
ally transmitted with position data when “COURSE/SPEED”
is selected.
NOTE: When “COURSE/SPEED” is selected, number of
character for “COMMENT” is limited to 36-character.
DD
Time stamp
Selects transmitting time stamp type from DHM, HMS and
OFF. This function can be transmitted UTC
(Universal Time Co-
ordinated) time only.
• OFF : No time stamp is transmitted.
(default)
• DHM : Time stamp in the format of Day, Hour and
Minute is transmitted.
• HMS : Time stamp in the format of Hour, Minute and
Second is transmitted.
DD
GPS-A symbol
Selects the desired GPS-A symbol.
Available symbols: Ambulance, Bus, Fire Truck, Bicycle,
Yacht, Helicopter, Small Aircraft, Ship
(Power Boat), Car
(default), Motorcycle,
Balloon, Jeep, Recreational Vehicle,
Truck, Van, Other
If “Other” is selected, set the desired symbol code as follows;
qPush [MAIN•BAND] to enter programming condition.
wRotate [DIAL] to select the 1st character from “\” and “/.”
ePush [>](M/CALL•MW)
(Left band’s) to select the 2nd digit.
rRotate [DIAL] to select the 2nd digit character.
tPush [MAIN•BAND] to program the symbol code.
When “Other” is selected, check the symbol codes of
APRS,
®
and set it correctly.
