■ Memory clearing
Contents of programmed memories can be cleared (blanked),
if desired.
qPush [V/MHz•SCAN] to select VFO mode in the desired
band
(left or right).
wPush and hold the same band’s [M/CALL•MW] for 1 sec.
•“X” indicator and the memory channel number blink.
eRotate [DIAL] to select the memory channel to be cleared.
rPush and hold [CLR](DUP•MONI) for 1 sec. to clear.
•3 beeps sound, then the frequency is cleared.
•“X” indicator and the channel number blink continuously.
• When clearing the call channel, the current VFO conditions are
re-programmed into the call channel automatically.
tPush [BACK](V/MHz•SCAN) (Right band’s) to return to VFO
mode.
NOTE: Be careful!— the contents of cleared memories
CANNOT be recalled.
[EXAMPLE]: Clearing memory channel 20.
Push (Main band’s) to select VFO.
Rotate (Main band’s) for selecting
memory channel to be cleared.
Push and hold (Main band’s) for 1 sec.
Push .
V/MHz
SCAN
V/MHz
SCAN
M/CALL
MW
Push and hold for 1 sec. memory clearing.
DUP
MONI
Beep
Beep
Beep
“
“
“
“
“
CLR BACK
M
A
I
N
B
A
N
D
