85
10
DTMF MEMORY ENCODER
■ DTMF speed
The rate at which DTMF values in memory send individual
DTMF characters can be set to accommodate operating
needs.
qPush [F•]to display the function guide.
wPush [MENU](V/MHz•SCAN)
(Right band’s) to enter MENU
screen.
eRotate [DIAL] to select
“DUP/TONE…,” then push
[MAIN•BAND].
rRotate [DIAL] to select
“DTMF SPEED,” then push
[MAIN•BAND].
tRotate [DIAL] to select the desired speed as shown in the
table below, then push [MAIN•BAND].
yPush [BACK](V/MHz•SCAN)
(Right band’s) twice to return
to frequency indication.
cps=characters/sec
DISPLAY INTERVAL SPEED
100 100 msec. 5.0 cps
200 200 msec. 2.5 cps
300 300 msec. 1.6 cps
500 500 msec. 1.0 cps
