DD
Comment
Program up to a 43-character* comment. The programmed
comment is transmitted with the GPS position data.
*36-character comment can only be programmed when
“COURSE/SPEED” is selected in data extension.
qPush [MAIN•BAND] twice to enter programming condition.
wRotate [DIAL] to select the desired character.
• Push [Aa](TONE•DTMF) to turn the character group from al-
phabetical characters capital letters or lower case letters.
• Push [1/](M/CALL•MW) (Right band’s) to turn the character
group from numbers or symbols.
• Push [>](M/CALL•MW) (Left band’s) or [<](V/MHz•SCAN) (Left
band’s) to move the cursor right or left, respectively.
• Push [CLR](DUP/MONI) to clear the selected character.
• Push and hold [CLR](DUP/MONI) for 1 sec. to clear all charac-
ters after the selected character.
eRepeat steps w until the desired comment is programmed.
rPush [MAIN•BAND] to set the programmed comment.
tPush [BACK](V/MHz•SCAN)
(Right band’s) to return to the
GPS-A set mode screen.
