SPECIFICATIONS AND OPTIONS
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
OPC-1712
CONTROLLER CABLE
For single body installation. Same as that supplied with the trans-
ceiver. 10 cm
SP-10
EXTERNAL SPEAKERS
For all-round mobile operation. Cable length: 1.5 m
UT-123
DIGITAL
/
GPS UNIT
Allows to digital voice mode operation. GPS receiver is included for
GPS and GPS-A operation. A GPS antenna is supplied with the unit.
MB-65
MOUNTING BASE
Mounts the remote controller on to variety of place in vihicle. Remote
controller bracket is required for mounting.
