DWS-3160 Series Gigabit Ethernet Unified Switch Web UI Reference Guide
496
(124)
has been reached the
user will be
disconnected. If the
attribute is 0 or not
present, then use the
value configured for the
Captive Portal.
Vendor-Specific (26),
D-Link (171),
LVL7-Max-Output-Octets
(125)
Maximum number of
octets the user is allowed
to receive. After this limit
has been reached the
user will be
disconnected. If the
attribute is 0 or not
present, then use the
value configured for the
Captive Portal.
Integer Optional 0
Vendor-Specific (26),
D-Link (171),
LVL7-Max-Total-Octets
(126)
Maximum number of
octets the user is allowed
to transfer (sum of octets
transmitted and
received). After this limit
has been reached the
user will be
disconnected. If the
attribute is 0 or not
present, then use the
value configured for the
Captive Portal.
Integer
Optional
0
Vendor-Specific (26),
D-Link (171),
LVL7-Captive-Portal-Groups
(127)
Acomma-delimited list of
group names that
correspond to the
configured CP instance
configurations.
String
Optional
None.
The
default
group is
used if
not
defined
here.
