Dc Inverter VRF plus Water Heater Solution Service Manual SERVICING
274
5
． Disassembly of axial flow
fan
①Disassemle retaining
nuts for the fans
②Remove fans
6． Disassembly of motor
①Disassemble the screws
for motor
②Replace motor
7 ． Replace motor and
assemble the unit according
to the reversed steps
①Replace motor and
assemble the unit
according to the reversed
steps and then inspect the
unit when energization.
