Dc Inverter VRF plus Water Heater Solution Service Manual SERVICING
Removal and Installation of Drainage Pump
Step Illustration Handling Instruction
1. Loosen the screws fixing
the water tray
● Use screwdriver to
loosen the screws fixing
the water tray
2. Remove the water tray
● Remove the water
pump and replace it.
3. Pull out the water outlet
pipe and loosen the screws
fixing the water pump.
●Pull out the water outlet
pipe and use screwdriver
to loosen the screws
fixing the water pump
4 Remove the water pump
and replace it.
● Remove the water
pump and replace it.
5. Connect the drainage hose
and tighten the screws fixing
the water pump.
●Connect the drainage
hose and use
screwdriver to tighten the
screws fixing the water
pump.
6. Mount the water tray and
tighten the screws
● Use screwdriver to
tighten the screws fixing
the water tray
1.Loosen the water outlet pipe
2.Loosen the screws
fixing the water pump
1.Tighten the drainage pipe
2.Tighten the screws fixing
the draina
g
e pump
