Dc Inverter VRF plus Water Heater Solution Service Manual SERVICING
291
★
GMV-Pds224W/Na-M.GMV-Pds280W/Na-M
23 4-way valveFittings ( solenoid coil ) 4300040029 1
24 Filter φ19 07210037 1
25 4-way valve sub-assy2 04144166 1
26 4-way valve(3.5hp)(R410A) 4300008201 1
27 4-way valveFittings ( solenoid coil ) 4300040031 1
28 Rear side plate 01314168P 1
29 Handle 26235253 3
30 Cut-off valve 3/8(R410A) 07130209 1
31 Cut-off valve 1/2(R410A) 07130210 1
32 Cut-off valve 3/4(R410A) 07130212 1
33 Gas valveSub-assy 07103030 1
34 Valve SupportSub-assy 01804156P 1
35 One-way valve 04324001 1
36 Filter 07212121 2
37 Electric expansion valve sub-assy2 07334337 1
38 Electric expansion valve SPF-18D88 07334193 1
39 Electric expansion valve coil 4300010811 1
40 Solenoid Valve Fittings ( solenoid coil ) 4304000428 1
41 Solenoid Valve FDF6A 43000072 1
42 Oil Separator 07228302 1
43 Oil SeparatorSub-assy 07424136 1
44 Liquid Accumulator (with 3 pipes 07424135 1
45 Pressure Switch (with leading-out wire) 4602000902 1
46 Discharge pipeSub-assy 04634235 1
47 PFCInductance 43120122 1
48 Mounted PlateSub-assy 01844134P 1
49
Compressor and Fittings
5VD420ZAA21
00205224 1
50 Isolation sheet sub-assy2 01244136 1
51 Inductance box 01424173 1
