Dc Inverter VRF plus Water Heater Solution Service Manual SERVICING
293
10
Axes flow wind leaf sub-assy
(VPd280)(black)
10338702 1
11 Motor support 0132431501P 2
12 Motor SWZ750A 15704106 1
13 Motor support sub-assy 01324180P 1
14 4-way valve sub-assy A 04144176 1
15 4-way valve sub-assy B 04144177 1
16 suction pipe sub-assy 04674202 1
17 Oil return pipe sub-ass 04324820 1
18 Liquid branch circuit valve sub-assy 1 04324826 1
19 Oil return pipe sub-assy Support 01804219P 1
20 Low pressure measure valve 322101002 1
21 liquid-gas separator 07424148 1
22 Displacement pipe sub-assy 1 04634248 1
23
Compressor and it’s fittings
E405DHD-38D2Y
00204116 1
24 lower panel sub-assy 01194307P 1
25
Compressor fixing support sub-assy
01324331P 1
26 oil separator 07423202 1
27
Compressor and it’s fittings
E505DH-49D2Y
00204124 1
28 Liquid pipe cut-off valve sub-assy 07304119 1
29 desiccation filter sub-assy 07414129 1
30 Support 01804166P 1
31 Displacement pipe sub-assy 2 04634249 1
32 Gas pipe cut-off valve sub-assy 07304118 1
33 Electrical expansion vavle sub-assy 1 07334355 1
34 Electrical expansion vavle sub-assy 2 07334356 1
35 liquid receiver 07424157 1
36 handle(apricot ash) 26235253 2
37 Back grill 01238740 1
38 Panel Front 01543243P 1
39 Fixing support sub-assy 3 01313259P 1
40 Sustain lengthways girder 01894156P 1
41 Sustain transverse girder sub-assy 01874132P 1
42 lower seat transverse girder 01874115P 2
43 Package wooden base 51094102 1
44 lower seat lengthways girder sub-assy 01874137P 2
45 cover of electrical box 01264173P 1
46 Terminal board 2-8 42011103 2
47 Main Board WZ6P30A 30226226 1
48 Main Board ZQ86 30228606 1
49 radiator SRX11D250 49010605 1
50 radiator 49018761 1
51 Main Board WZS901 30229004 1
52 AC Contactor LC1D25M7C 44010213 1
53 Electric element install Board sub-assy 2 01324319 1
54 Terminal Board (4 bit) 42011051 1
55 electrical box sub-assy 01394839P 1
56 Over Current Protector (3/40A)
OSMC32N3C40
45020214 1
57 Anti-phase Protector EWS 46020054 1
58 AC Contactor CJX9B-25S/D 44010245 1
59 filter board WZ814A 30228111 1
60 Electric element install Board sub-assy 1 01324318 1
61 Electric element install Board sub-assy 4 01324324 1
62 reactor L1.92mH/34A/10/300+400 43130174 1
63 Power Transformer 66X32 43110012 1
64 Electric element install Board sub-assy 1 01324345 1
65 filter FN2090-16-06 43130016 1
