Dc Inverter VRF plus Water Heater Solution Service Manual SERVICING
316
No
Part Name
Code
Qty
GMV-R22PS/NaB
-K
GMV-R28PS/NaB-
K
GMV-R36PS/NaB-
K
1 Side Plate of Air outlet
01494118
1 1 1
2 Left Support of Evaporator
01094122
1 1 1
3 Evaporator Assy
01024231
1
01024230
1
01024232
1
4
Electric expand valve
fitting
43040001
1 1 1
5
Right Support o
f
Evaporator
01094121
1 1 1
6 Left Side Plate Sub-assy
01314172
1 1 1
7
Seal of left side Plate
Sub-assy
01494115
1 1 1
8
Seal of left Connectio
n
Pipe Sub-assy
01494116
1 1 1
9 Hook
02112446
4 4 4
10 Electric Box Cover
01424319
1 1
11 Top Cover Board Assy
01264176
1 1 1
12
Right Side Plate Sub
-assy
01314175
1 1 1
13 Motor Support
0170905801
1 1 1
14 Fan Motor
1570520103
1
1570520201
1 1
15 Motor Sub-assy
150024011
1 1 1
16
Border Plate Assy of Ai
r
Return End
02225234
1 1 1
17 Filter
11725202
1 1 1
18 Electric Box
01394977
1 1 1
19
Lower Cover Plate
Sub-assy
01264178
1 1 1
20
Fan motor mounting Plate
Sub-assy
01324341
1 1 1
21 Water Pump Assy
15404117
1 1 1
22 Terminal Border
42011106
1 1 1
23 Capacitor
33010027
1 1 1
24 Transformer
43110237
1 1 1
25 Main Bord
30226222
1 1 1
26 Connecting Wire
4001039509
1 1 1
27 Display Bord
30296014
1 1 1
28 Sensor sub-assy
39008026
1 1 1
