Dc Inverter VRF plus Water Heater Solution Service Manual SERVICING
317
No
Part Name
Code
Qty
GMVL-R45PS/NaB-K GMVL-R45P/NaB-K
1 Side Plate of Air outlet
01498641
1 1
2 Left Support of Evaporator
01805280
1 1
3 Evaporator Sub-assy
01024211
1 1
4 Electric expand valve fitting
43040001
1 1
5 Right Support of Evaporator
01078625
1 1
6
Left Side Plate Sub
-assy
01314230
1 1
7 Seal of left side Plate Sub-assy
01494128
1 1
8 Seal of Connection Pipe Sub-assy
01498640
1 1
9 Hook
02112466
4 4
10 Electric Box Cover
01425249
1 1
11 Top Cover Board Assy
01259064
1 1
12
Right Side Plate Sub
-assy
01308670
1 1
13 Motor Support
01709056
1 1
14 Fan Motor
1501832202
1 1
15 Motor Sub-assy
15002401
2 2
16 Border Plate Assy of Air Return End
02225234
1 1
17 Filter
11725202
1 1
18 Electric Box
01394739
1 1
19 Lower Cover Plate Sub-assy
01265296
1 1
20 Fan motor mounting Plate Sub-assy
01339058
1 1
21 Water Pump Assy
15404121
1 0
22 Terminal Border
42011106
1 1
23 Capacitor
33010010
1 1
24 Transformer
43110237
1 1
25 Main Bord
30226221
1
30226167
1
26 Connecting Wire
4001039509
1 1
27 Display Bord
30296013
1 1
28 Sensor sub-assy
39004167
1 1
