Dc Inverter VRF plus Water Heater Solution Service Manual SERVICING
324
No
Part Name
Code
Qty
GMVL-R90P/NaB
-K
GMVL-R112P/Na
B-K
GMVL-R140P/N
aB-K
1 Air outlet side board assy
01498608
1 1 1
2 Water pump assy
15404119
0 0 0
3 Water level switch
45010201
0 0 0
4 Electric expand valve fitting
43040001
1 1 1
5 Evaporator assy
01024222
1 1
01024218
1
6 Left support of evaporator
01805279
1 1
01804703
1
7
Fan motor mounting Plate
Sub-assy
01324356
1 1
01804703
1
8 Top Cover Board Assy
01258607
1 1
01264627
1
9 Right support of evaporator
01078604
1 1
01805221
1
10 Right Side Plate Sub-assy
01308679
1 1
11 Air intake side-board sub-assy
01375221
1 1 1
12 Filter Sub-assy
11725205
1 1 1
13 Fan Motor
15018603
2 2 2
14 Fan Motor
15018604
1 1 1
15 Motor
1570521101
1 1
1570520901
1
16 Motor
1570521201
1 1
1570521001
1
17 Bottom cover plate assy
01258603
1 1
0125860301
1
18 Cover of air-in
01258602
1 1 1
19 Water tray assy
01278603
1 1
01285229
1
20 Electric box assy
01394963
1 1
01394964
1
21 Capacitor
33010014
1 1
33010056
1
22 Capacitor
33010064
1 1 1
23 Terminal board
42011106
1 1 1
24 Transformer
43110239
1 1 1
25 Main board
30226167
1 1 1
26 Electric box cover
01425249
1 1 1
27 Seal of lefr side plate sub-assy
01308672
1 1
01495212
1
28 Left side plate assy
01315255
1 1 1
29 Seal of connection pipe
01498601
1 1
01495213
1
30 Hook
02118504
4 4 4
31 Connecting Wire
4001039509
1 1 1
32 Display board
30296013
1 1 1
33 Sersor sub-assy
39004167
1 1 1
