Dc Inverter VRF plus Water Heater Solution Service Manual SERVICING
325
No
Part Name
Code
Qty
GMVL-R90PS/NaB-
K
GMVL-R112PS/NaB-
K
GMVL-R140PS/Na
B-K
1 Air outlet side board assy 01498608 1 1 1
2 Water pump assy
15404119 1 1
15404118 1
3 Water level switch
45010201 1 1
450102012 1
4 Electric expand valve fitting 43040001 1 1 1
5 Evaporator assy
01024233 1 1
01024218 1
6 Left support of evaporator
01805279 1 1
01804703 1
7
Fan motor mounting Plate
Sub-assy
01324356 1 1
01325293 1
8 Top Cover Board Assy
01258607 1 1
01264627 1
9 Right support of evaporator
01078604 1 1
01805221 1
10 Right Side Plate Sub-assy 01308679 1 1
11
Air intake side-
b
oar
d
sub-assy
01375221 1 1 1
12 Filter Sub-assy 11725205 1 1 1
13 Fan Motor 15018603 2 2 2
14 Fan Motor 15018604 1 1 1
15 Motor
1570521101 1 1
1570520901 1
16 Motor
1570521201 1 1
1570521001 1
17 Bottom cover plate assy
01258603 1 1
0125860301 1
18 Cover of air-in 01258602 1 1 1
19 Water tray assy
01284160 1 1
01284157 1
20 Electric box assy
01394998 1 1
01394999 1
21 Capacitor
33010014 1 1
33010056 1
22 Capacitor 33010064 1 1 1
23 Terminal board 42011106 1 1 1
24 Transformer 43110239 1 1 1
25 Main board 30226221 1 1 1
26 Electric box cover 01425249 1 1 1
27
Seal of lefr side plate
sub-assy
01494125 1 1
01494121 1
28 Left side plate assy
01494124 1 1
01314222 1
29 Seal of connection pipe
01494123 1 1
01494120 1
30 Hook 02118504 4 4 4
31 Connecting Wire 4001039509 1 1 1
32 Display board 30296013 1 1 1
33 Sersor sub-assy 39004167 1 1 1
