Dc Inverter VRF plus Water Heater Solution Service Manual SERVICING
341
GMV(L)-R28Td/Na-K.GMV(L)-R36Td/Na-K Parts List
S/N Part Name Qty
Code
GMV-R28Td/Na-K；
GMV-R36Td/Na-K
GMVL-R28Td/Na-；
GMVL-R36Td/Na-K
1
Panel Assy
（MT01top）
1 TL1000120 TL1000120
2 Water Tray Assy 1 12412702 12412702
3 Water Diversion 1 24212708 24212708
4 Evaporator Assy 1 01024104 01024104
5 Right Side PlateAssy 1 01302729 01302729
6 Cross Flow Fan 1 10352701 10352701
7 electric heating pipe Assy
— —— ——
8 SoleplateAssy 1 01222714 01222714
9 Right Side PlateAssy 1 01302746 01302746
10 Rear CaseAssy 1 22202702 22202702
11 Motor 1 15018762 15018762
12 Electric boxAssy 1 01404655 01404697
13 Mainboard 1 30226034 30226033
14 Electric boxcover plate 1 01412725 01412725
15 Protective Cover of Patching Board 1 222427221 222427221
16 Draining Pump 1 43132701 43132701
17 Electric expansion valve Assy 1 07334129 07334129
18 Support 1 01792703 01792703
