Dc Inverter VRF plus Water Heater Solution Service Manual SERVICING
355
No. Part Name
GMV(L)-R28Zd/Na-K,GMV(L)-R36Zd/Na-K,GMV(L)-R50Zd/Na-K
Code Qty.
1 Rear Side Plate 01302013 1
2 Handle 26232001 4
3 Left Decoration Plate 261124152 1
4 Rear Side Plate of Air Outlet 0130201501 1
5 Louver 1051953202 1
6 Right Decoration Plate 261124162 1
7 Shaft of Louver II 10512026 2
8 Louver Support 24212019 2
9 Shaft of Louver I 10512025 1
10 Louver Fixer 24212018 1
11 Swing Louver 10512027 12
12 Connecting Lever 10582009 1
13 Connecting Lever 10582008 2
14 Right Swing Motor Fixer 26152006 1
15 Right Fixing Plate of Evaporator 01072411 1
16 Right Side Foam sub-assy 12312404 1
17 Right Fixing Plate 01332404 1
18 Right Decoration Panel 26112027 1
19 Pipe Clamp Plate 0107243701 1
20 Capacitor 1uF/500V 33010089 1
21 Transformer 57X25C 43110237 1
22 Electric Box 01402407 1
23 Main PCB Z6935 30226903 1
24 Terminal Board RS9413G 42011159 1
25 Wire Base 24253001 1
Wire Clamp 24253002 1
26 Fuse 5A 250VAC 46010013 1
27 Cover of Electric Box 01412408 1
28 Pipe Clip 70812001 1
29 Drainage hose 05235433 1
30 Display Board 5T52
30545654
1
31 Electric Box 20102138 1
32 Front Grill Clip 1 26252002 4
33 Filter 11122013 2
34 Front Grill 22412010 2
35 Front Grill Clip 2 26252003 4
36 Front Panel 01544106 1
37 Front Panel 01532001P 1
38 Water Tray Panel 01272205P 1
39 Motor Support 01709532 1
40 Left Decoration Panel 26112028 1
41 Left Fixing Plate 01332405 1
