Dc Inverter VRF plus Water Heater Solution Service Manual SERVICING
356
No. Part Name
GMV(L)-R28Zd/Na-K,GMV(L)-R36Zd/Na-K,GMV(L)-R50Zd/Na-K
Code Qty.
43 Left Fixing Plate of Evaporator 01072410 1
44 Motor Clamp 26112026
4
45 Step Motor MP35CA 15212402 2
46 Left Swing Motor Fixer 26152005 1
47 Evaporator Assy
01024134
①
1
01024135 ②
1
01024121 ③
1
48 Water Lead Panel 01362001 1
49 Cover of Evaporator 01072409 1
50 Fixed Mount 01708763 1
51 Centrifugal Fan 10312401 2
52 Rear Snail Shell 22202032 2
53 Front Snail Shell 22202031 2
54 Bar Clasp 70819522 4
55 Hoop 70819521 1
56
Motor
15707302 ④
1
157073024 ⑤
1
57 Remote Controller 305125063 1
58 Signal Cable 400103953 1
59 Fix sub-assy 01324110P 1
60 EXV sub-assy 07334258 1
61 EXV SPF-16D70 07334191 1
62 Magnet Coil for EXV DPF-AS001A 430001087 1
63 Display Board Z63351F 30296309 1
Note:
a) Evaporator Assy ① is only applicable to GMV(L)-R28Zd/Na-K
b) Evaporator Assy
② is only applicable to GMV(L)-R36Zd/Na-K
c) Evaporator Assy
③ is only applicable to GMV(L)-R50Zd/Na-K
d) Motor
④ is only applicable to GMV(L)-R28Zd/Na-K,GMV(L)-R36Zd/Na-KMotor
e) Motor
⑤ is only applicable to GMV(L)-R50Zd/Na-K
