Dc Inverter VRF plus Water Heater Solution Service Manual SERVICING
361
No. Part Name
GMV(L)-R90Zd/Na-K,
GMV(L)-R112Zd/Na-K,
GMV(L)-R125Zd/Na-K
Code Qty.
1 Left Decoration Plate 261124152 1
2 Shaft of Louver I 10512025 3
3 Swing Louver Fixer sub-assy 0133241802 1
4 Louver Support 24212019 4
5 Louver Fixer 24212018 3
6 Shaft of Louver II 10512026 2
7 Louver 105124082 1
8 Right Decoration Plate 261124162 1
9 Left Swing Motor Fixer 26152005 1
10 Front Panel 01532413 1
11 Display Box 20102138 1
12 Display Board 5T52 30545654 1
13 Front Panel 01544106 1
14 Right Swing Motor Fixer 26152006 1
15 Step Motor MP35CA 15212402 2
16 Motor Clamp 26112026 4
17 Water Tray 0127240802 1
18 Auxiliary Water Tray 01272409 1
19 Pipe Clip 70812001 1
20 Drainage hose 05235433 1
21 Handle 26232001 4
22 Right Side Foam sub-assy 12312404 1
23 Right Fixing Palte 01332404 1
24 Support of Motor Bearing 01792408 2
25 Fixer of Motor Support 01792407 1
26 Right Decoration Panel 26112027 1
27 Pipe Clamp 01072425 1
28 Electric Box 01402407 1
29 Wire Base 24253001 1
30 Wire Clamp 24253002 1
31
Terminal Board
42011159
1
32 Fuse 5A 250VAC 46010013 1
33 Main PCB Z6935
30226903
1
34 Ring of Bearing 76512404 2
35 Fan Bearing 76512210 1
36 Transformer 57×25C 43110237 1
37 Cover of Electric Box 01412408 1
38 Centrifugal Fan 10319051 4
39 Rotary Axis 73012402 2
40 Capacitor
33010064 ① 1
33010056 ② 1
41 Motor
15012405 ③ 1
15012404 ④ 1
