Dc Inverter VRF plus Water Heater Solution Service Manual SERVICING
362
42 Motor Fixer 01722410 1
43 Motor Clamp 01702405 2
44 Axes Connector 73012403 2
45 Motor Fixing Plate 01332425 1
46 Front Snail Shell 22202030 4
47 Rear Snail Shell 22202029 4
48 Rear Side Plate 01302431 1
49 Motor Support 01702411 1
50 Filter 11122013 1
51 Water Lead Plate 01362407 1
52 Front Grill 22412010 4
53 Front Grill Clip 2 26252003 8
54 Remote Controller 305125063 1
55 Evaporator Assy 01024122 1
56 Front Grill Clip 1 26252002 8
57 Cover of Evaporator 01072409 1
58 Left Decoration Panel 26112028 1
59 Left Fixing Plate 01332405 1
60 Left Side Foam sub-assy 12312403 1
61 Bearing Fixing Plate 01332406 1
62 Rear Side Plate of Air Outlet 01302416 1
63 Connecting Lever 10582008 2
64 Connecting Lever 10582009 4
65 Swing Louver 10512027 26
66 Signal Cable 400103953 1
67 Display Board Z63351F 30296309 1
68 EXV sub-assy 07334256 1
69 EXV VPF-25D*B3 07334195 1
70 Magnet Coil for EXV 43000110 1
71 Fix sub-assy 2 01324110P 1
Note:
a) Capacitor ① is only applicable to GMV(L)-R90Zd/Na-K
b) Capacitor
② is only applicable to GMV(L)-R112Zd/Na-K,GMV(L)-R125Zd/Na-K
c) Motor
③ is only applicable to GMV(L)-R90Zd/Na-K
d) Motor
④ is only applicable to GMV(L)-R112Zd/Na-K,GMV(L)-R125Zd/Na-K
