Dc Inverter VRF plus Water Heater Solution Service Manual PRODUCT
33
Model GMV(L)-R22Td/Na-K GMV(L)-R28Td/Na-K GMV(L)-R36Td/Na-K
Cooling Capacity
kW 2.2 2.8 3.6
Btu 7506 9550 12280
Heating Capacity
kW 2.5 3.2 4.0
Btu 8530 10900 13650
Air Flow Rate
m3/h 450 500 500
CFM 265 294 294
Sound Pressure Level (H/L) dB(A) 45/41 45/41 45/41
External Static Pressure Pa / / /
Power Supply
220-240V～50Hz 220-240V～50Hz 220-240V～50Hz
Fan Motor
Output kW 0.02 0.02 0.02
Running
Current
A 0.22 0.22 0.22
Connecting
Pipes
Gas Pipe
mm Φ9.52 Φ9.52 Φ12.7
inch
3/8＂ 3/8＂ 1/2＂
Liquid Pipe
mm Φ6.35 Φ6.35 Φ6.35
inch
1/4＂ 1/4＂ 1/4＂
Connection Method Flare Connection Flare Connection Flare Connection
Drain Pipes
(External Dia. × Thickness)
mm
Φ30×1.5 Φ30×1.5 Φ30×1.5
Unit Dimensions
(W×D×H)
mm
Main body：920×360×185 Panel：1180×430×30
Package Dimensions
(W×D×H)
mm
Main body：1290×465×270 Panel：1260×505×110
Net Weight
(Main body/Panel)
kg 16/3
Gross Weight
(Main body/Panel)
kg 25/5
Notes:
① Refer to the product nameplate for parameters and specification of the unit;
② The model with GMVL code is cooling only unit; while the model with GMV code is heat pump unit; the
cooling only units dose not have any parameters of performing heating;
③ The sound level was tested under circumstance of semi-anechoic chamber; the value of noise could be a
little higher in actual operation
