Dc Inverter VRF plus Water Heater Solution Service Manual PRODUCT
34
4.2.3Wall mounted Type
Model GMV(L)-R22G/NaB-K GMV(L)-R28G/NaB-K GMV(L)-R36G/NaB-K
Cooling Capacity
kW
2.2
2.8 3.6
Btu 7507 9554 12284
Heating Capacity
kW
2.5
3.2 4.0
Btu 8530 10919 13649
Air Flow Rate
m3/h 360 360 500
CFM
212
212 294
Sound Pressure Level
(H/L)
dB(A) 37/28 37/28 43/28
External Static Pressure Pa / / /
Power Supply 220-240V-1Ph-50Hz 220-240V-1Ph-50Hz 220-240V-1Ph-50Hz
Fan
Motor
Output kW 0.014 0.014 0.022
Running
Current
A 0.15 0.15 0.22
Connect
ing
Pipes
Gas Pipe
mm
Φ9.52 Φ9.52 Φ12.7
inch
Φ3/8 Φ3/8
Φ1/2
Liquid Pipe
mm
Φ6.35 Φ6.35 Φ6.35
inch Φ1/4 Φ1/4 Φ1/4
Connection Method Flare Connection Flare Connection Flare Connection
Drain Pipes
（External Dia. ×
Thickness）
mm φ20×1.5 φ20×1.5 φ20×1.5
Unit Dimensions
(W×D×H)
mm 830×189×285 830×189×285 830×189×285
Package Dimensions
(W×D×H)
mm 995×394×268 995×394×268 995×394×268
Weight（Net/Gross）
kg 8/14.3 8/14.3
11/15.8
Notes:
① Refer to the product nameplate for parameters and specification of the unit;
② The model with GMVL code is cooling only unit; while the model with GMV code is heat pump unit; the
cooling only units does not have any parameters of performing heating;
③ The sound level is tested under circumstance of semi-anechoic chamber; the value of noise could be a
little higher in actual operation.
