Dc Inverter VRF plus Water Heater Solution Service Manual PRODUCT
35
Model GMV(L)-R45G/NaB-K GMV(L)-R50G/NaB-K GMV(L)-R56G/NaB-K
Cooling Capacity
kW
4.5
5.0 5.6
Btu 15355 17061 19108
Heating Capacity
kW
5.0
5.8 6.3
Btu 17061 19790 21496
Air Flow Rate
m3/h 500 700 750
CFM
294
412 441
Sound Pressure Level (H/L) dB(A) 43/28 45/40 45/40
External Static Pressure Pa / / /
Power Supply 220-240V-1Ph-50Hz 220-240V-1Ph-50Hz 220-240V-1Ph-50Hz
Fan
Mot
or
Output kW 0.022 0.02 0.02
Running
Current
A 0.22 0.25 0.26
Connecti
ng
Pip
es
Gas Pipe
mm
Φ12.7 Φ12.7 Φ15.9
inch
Φ1/2 Φ1/2
Φ5/8
Liquid Pipe
mm
Φ6.35 Φ6.35 Φ9.52
inch Φ1/4 Φ1/4 Φ3/8
Connection Method Flare Connection Flare Connection Flare Connection
Drain Pipes
（External Dia. ×
Thickness）
mm Φ20×1.5 Φ30×1.5 Φ30×1.5
Unit Dimensions
(W×D×H)
mm 830×189×285 1020×228×310 1020×228×310
Package Dimensions
(W×D×H)
mm 1006×385×265 1178×325×390 1178×325×390
Weight（Net/Gross） kg 11/15.8 15.5/20.5 15.5/20.5
Notes:
① Refer to the product nameplate for parameters and specification of the unit;
② The model with GMVL code is cooling only unit; while the model with GMV code is heat pump unit; the
cooling only units does not have any parameters of performing heating;
③ The sound level is tested under circumstance of semi-anechoic chamber; the value of noise could be a
little higher in actual operation.
