Dc Inverter VRF plus Water Heater Solution Service Manual PRODUCT
36
Model GMV(L)-R22G/NaC-K GMV(L)-R28G/NaC-K GMV(L)-R36G/NaC-K
Cooling Capacity
kW 2.2 2.8 3.6
Btu 7507 9554 12284
Heating Capacity
kW 2.5 3.2 4.0
Btu 8530 10919 13649
Air Flow Rate
m3/h 360 360 500
CFM 212 212 294
Sound Pressure Level
(H/L)
dB(A) 37/28 37/28 43/28
External Static Pressure Pa / / /
Power Supply
220-240V-1Ph-50Hz 220-240V-1Ph-50Hz 220-240V-1Ph-50Hz
Fan Motor
Output kW 0.014 0.014 0.022
Running
Current
A 0.15 0.15 0.22
Connecting
Pipes
Gas Pipe
mm Φ9.52 Φ9.52 Φ12.7
inch
3/8＂ 3/8＂ 1/2＂
Liquid
Pipe
mm Φ6.35 Φ6.35 Φ6.35
inch
1/4＂ 1/4＂ 1/4＂
Connection Method Flare Connection Flare Connection Flare Connection
Drain Pipes
（External Dia. ×
Thickness）
mm
φ20×1.5 φ20×1.5 φ20×1.5
Unit Dimensions
(W×D×H)
mm
770×190×250 770×190×250 830×189×285
Package Dimensions
(W×D×H)
mm
955×330×272 955×272×330 1006×395×295
Weight（Net/Gross）
kg 8/14.3 8/14.3 11/15.8
Notes:
① Refer to the product nameplate for parameters and specification of the unit;
② The model with GMVL code is cooling only unit; while the model with GMV code is heat pump unit; the
cooling only units dose not have any parameters of performing heating;
③ The sound level was tested under circumstance of semi-anechoic chamber; the value of noise could be a little
higher in actual operation.
