Dc Inverter VRF plus Water Heater Solution Service Manual PRODUCT
37
Model GMV(L)-R45G/NaC-K GMV(L)-R71G/Na-K GMV(L)-R80G/Na-K
Cooling Capacity
kW 4.5 7.1 8.0
Btu 15355 24226 27297
Heating Capacity
kW 5.0 8.0 9.0
Btu 17061 27297 30709
Air Flow Rate
m3/h 500 1200 1200
CFM 294 706 706
Sound Pressure Level
(H/L)
dB(A) 43/28 49/42 49/42
External Static Pressure Pa / / /
Power Supply
220-240V-1Ph-50Hz 220-240V-1Ph-50Hz 220-240V-1Ph-50Hz
Fan Motor
Output kW 0.022 0.026 0.026
Running
Current
A 0.22 0.29 0.39
Connecting
Pipes
Gas Pipe
mm Φ12.7 Φ15.9 Φ15.9
inch
1/2＂ 5/8＂ 5/8＂
Liquid
Pipe
mm Φ6.35 Φ9.52 Φ9.52
inch
1/4＂ 3/8＂ 3/8＂
Connection Method Flare Connection Flare Connection Flare Connection
Drain Pipes
（External Dia. ×
Thickness）
mm
Φ30×1.5 φ30×1.5 φ30×1.5
Unit Dimensions
(W×D×H)
mm
830×189×285
1178×227×326 1178×227×326
Package Dimensions
(W×D×H)
mm
1006×395×295
1365×417×333 1365×417×333
Weight（Net/Gross）
kg 11/15.8 17.5/23 17.5/23
Notes:
① Refer to the product nameplate for parameters and specification of the unit;
② The model with GMVL code is cooling only unit; while the model with GMV code is heat pump unit; the cooling
only units dose not have any parameters of performing heating;
③ The sound level was tested under circumstance of semi-anechoic chamber; the value of noise could be a little
higher in actual operation.
