Dc Inverter VRF plus Water Heater Solution Service Manual PRODUCT
39
Model GMV(L)-R71Zd/Na-K GMV(L)-R90Zd/Na-K
Cooling Capacity
kW
7.1
9.0
Btu 24226 30709
Heating Capacity
kW
8.0
10.0
Btu 27297 34121
Air Flow Rate
m3/h 1170 2100
CFM 689 1236
Sound Pressure Level (H/L) dB(A) 48/- 51/-
External Static Pressure Pa / /
Power Supply 220-240V-1Ph-50Hz 220-240V-1Ph-50Hz
Fan Motor
Output kW 0.1 0.15
Running Current A 1 1.5
Connecting
Pipes
Gas Pipe
mm Φ15.9 Φ15.9
inch Φ5/8 5/8
Liquid Pipe
mm Φ9.52 Φ9.52
inch Φ3/8 3/8
Connection Method Flare Connection Flare Connection
Drain Pipes
（External Dia. × Thickness）
mm Φ17×1.75 Φ17×1.75
Unit Dimensions(W×D×H) mm 1300×188×600 1590×238×695
Package Dimensions(W×D×H) mm 1514×248×724 1714×330×830
Weight（Net/Gross） kg 34/38 44/53
Notes:
① Refer to the product nameplate for parameters and specification of the unit;
② The model with GMVL code is cooling only unit; while the model with GMV code is heat pump unit; the
cooling only units does not have any parameters of performing heating;
③ The sound level is tested under circumstance of semi-anechoic chamber; the value of noise could be a
little higher in actual operation.
