Chapter4 Router Configuration
3-10
Procedure
According to the different purposes, execute corresponding step. Please refer to the
following table.
Objective
Step
Globally enable
DHCP function
1. Use command of configure to enter the Global Configuration View;
2. Use command of dhcp start to globally enable DHCP function;
3. Done.
Configure
DHCP working
mode of interface
to be Server
1. Use command of configure to enter the Global Configuration View;
2. Use command of interface vlan vlan-id to enter the VLANIF
Configuration View;
3. Use command of ip dhcp server to configure DHCP working mode of
interface to be Server;
4. Done.
Configure
DHCP address
pool
1. Use command of configure to enter the Global Configuration View;
2. Use command of dhcp pool pool-number to create DHCP address
pool and enter the DHCP pool Configuration View;
3. Done.
Configure
DHCP dynamic
distributed IP
address range
and mask in the
address pool
1. Use command of configure to enter the Global Configuration View;
2. Use command of dhcp pool pool-number to enter the DHCP pool
Configuration View;
3. Use command of network range start-ip-address end- ip-address
mask mask-address or use command of network ip-address mask mask-
address to configure DHCP dynamic distributed IP address range and mask
in the address pool;
4. Done.
(Optional)
Configure the IP
address not
automatically
assigned in DHCP
address pool
1. Use command of configure to enter the Global Configuration View;
2. Use command of dhcp pool pool-number to enter the DHCP pool
Configuration View;
3. Use command of dhcp server forbidden-ip ip-address1
[ ip-address2 ] to Configure the IP address not automatically assigned in
DHCP address pool;
4. Done.
Configure the IP
address lease
time in DHCP
address pool
1. Use command of configure to enter the Global Configuration View;
2. Use command of dhcp pool pool-number to enter the DHCP pool
Configuration View;
3. Use command of lease-time { time | default } to configure the IP
address lease time in DHCP address pool;
4. Done.
Configure the
1. Use command of configure to enter the Global Configuration View;
