Chapter2 Layer 2 Ethernet Configuration
2-14
2.3.3 Display Layer 2 MAC Address Table
Purpose
This section introduces how to quickly locate the relevant information of the specified
MAC table item for user to query for specific information conveniently.
Procedure
According to the different purposes, execute corresponding step. Please refer to the
following table.
Objective
Step
Parameter
Check
Layer-2 static
forwarding
table
1. Enter the Common User View,
the Privilege User View or the
Global Configuration View;
2. Use one of the following
commands:
show mac-address MAC
show mac-address MAC vlan VID
show mac-address config
show mac-address verbose
VID: VLAN id, optional, integer with
range of 1~4094
MAC: static MAC address, form as
AA:BB:CC:DD:EE:FF, A~F is one hex
number
config: means to display MAC address
configuration information;
verbose: means to display detailed MAC
information except MAC configuration
information
2.4 ARP Configuration
ARP mapping table can dynamically be maintained or manually maintained. Usually
map the IP address manually configured to MAC address, it is called static ARP. User
can check, add and delete ARP mapping item in ARP table by related manually
maintained commands.
2.4.1 Add/Delete Static ARP Mapping Item Manually
Purpose
This section introduces how to add/delete static ARP mapping table manually.
Static ARP mapping table can only be configured manually and will not be influenced
by ARP mapping table aging time and at the same time also cannot dynamically
update this mapping relationship. Static ARP mapping table continues to be effective
during the working time of device.
Procedure
