Chapter2 Layer 2 Ethernet Configuration
2-20
Parameter
Description
Value
trunk-id
trunk ID
integer with range of 1~8
default interface LACP priority to be
32768
2.5.3 Maintenance and Debug
Purpose
When LACP function is abnormal, it needs to check and debug.
Procedure
According to the different purposes, execute corresponding step. Please refer to the
following table.
Objective
Step
Enable LACP
debug function
1. Use command of disable to exit to the Common User View or use
command of configure to enter the Global Configuration View or use
command of interface fastethernet interface-number or interface eth-trunk
trunk-number to enter the Interface Configuration View or keep the current
Privilege User View;
2. Use command of debug lacp
{ timer|event|churn|mux|rx|tx|logic|sync|all } to enable LACP debug function;
3. Done.
Disable LACP
debug function
1. Use command of disable to exit to the Common User View or use
command of configure to enter the Global Configuration View or use
command of interface fastethernet interface-number or interface eth-trunk
trunk-number to enter the Interface Configuration View or keep the current
Privilege User View;
2. Use command of no debug lacp
{ timer|event|churn|mux|rx|tx|logic|sync|all } to disable LACP debug function;
3. Done.
Check LACP
configuration file
information
1. Use command of disable to exit to the Common User View or use
command of configure to enter the Global Configuration View or use
command of interface fastethernet interface-number or interface eth-trunk
trunk-number to enter the Interface Configuration View or keep the current
Privilege User View;
2. Use command of show lacp config to display LACP configuration file
information;
3. Done.
Check all or
1. Use command of disable to exit to the Common User View or use
