Chapter4 Router Configuration
3-13
Parameter
Description
Value
must be even number, hex (such
as HH or HHHH)
len-range
IP address mask length
integer with range of 0-32
ipv6-address/MAS
IPv6 address prefix and prefix
length
128bits IP address is divided
into 8 groups, 16bits of each
group uses 4 hex characters
(0 ～ 9, A ～ F), use colon to
separate groups
option-range
option range
integer with range of 2-254
sub-option
sub-option range
integer with range of 1-254
ip-address
IPv4 address of sub-option
dotted decimal
3.2.6 Configure DHCP Server Security Function
Precondition
DCHP Server has been configured already.
Procedure
According to the different purposes, execute corresponding step. Please refer to the
following table.
Objective
Step
Bind IP address
of DHCP address
pool with user
MAC address
1. Use command of configure to enter the Global Configuration View;
2. Use command of dhcp server static-bind ip-address mac-address to
bind IP address of DHCP address pool with user MAC address;
3. Done.
Configure the
address repeated
detection interval
1. Use command of configure to enter the Global Configuration View;
2. Use command of dhcp address-check-time { checktime | default } to
configure the address repeated detection interval;
3. Done.
Configure
DHCP fake server
detection function
1. Use command of configure to enter the Global Configuration View;
2. Use command of dhcp server detect { enable | disable } to configure
DHCP fake server detection function;
3. Done.
Appendix List:
Parameter
Description
Value
ip-address
the binding IP address must be
the valid IP address in the address
dotted decimal
