Chapter1 Basic Configuration
1-23
1.4.1.5 FTP Delete File
Purpose
This section introduces how to delete file through FTP.
Process
According to the different purposes, execute corresponding step. Please refer to the
following table.
Purpose
Step
(IPv4)Delete
designate
file of FTP
server
1. Use command of configure to enter the Global Configuration View;
2. Use command of ftp delete ipv4-addressuser password remotefile or use
command of ftp delete ipv4-address user password remotefile [ port-id ] to
delete designated file of FTP server;
3. Done.
(IPv6)Delete
designate
file of FTP
server
1. Use command of configure to enter the Global Configuration View;
2. Use command of ftp6 delete ipv6-address user password remotefile or
use command of ftp6 delete ipv6-address user password remotefile [ port-id ]
to delete designated file of FTP server;
3. Done.
Appended List:
Parameter
Description
Value
ipv4-address
Host IPv4 address
Dotted decimal
ipv6-address
Host IPv6 address
In the IPv6 address form, 128 bits IP
address is distributed as 8 groups that 12 bits
in each group is indicated with 4 hexadecimal
characters (0~9, A~F) and separated with
punctuation „:‟, where each „X‟ is indicating a
group of hexadecimal value
user
Username for FTP service
login
String form with length 1~63
password
Password for FTP service
login
String form with length 1~63
remotefile
File name that is to be
downloaded to the host
String form with length 1~63
[ port-id ]
Port number, optional
configuration
Integer form with value range between
1~65535
