Chapter1 Basic Configuration
1-5
If settings are performed according to above processes and the device is in normal
operation, there will be hyper terminal interface displayed Login Interface of Hyper
Terminal indicating the hyper terminal has been successfully logging into the QSW-
2800 Switch.
1.3.2 Login through Telnet
Purpose
Besides hyper terminal, the login of QSW-2800 Switch can also be achieved through
telnet. The serial port provided by the QSW-2800 Switch offers regular version
upload, upgrade and maintenance only.
The section introduces how to use local PC to log into QSW-2800 Switch through
telnet. Local PC telnet supports local and remote user login which is easy for
maintenance.
Precondition
Before the login of QSW-2800 Switch via telnet, the user shall confirm the following
issue:
The QSW-2800 Switch is „ping‟ available with local PC.
Network Requirement
When logging to QSW-2800 Switch via telnet, there shall be direct network cable
connection or connection with hub.
Once the telnet is utilized for login, the QSW-2800 Switch must be configured as
telnet user with username and password.
Process
The processes of telnet login are as follows:
1. Input username and password (QSW-2800 Switch initialized username
is, admin and password is 12345)
2. Designate IP address to QSW-2800 Switch for telnet user access.
3. Select [Start Run] under Windows OS environment.
Input command „telnet x.x.x.x‟ in the column of „Run‟ dialog, where
„x.x.x.x‟ indicates IP address of the QSW-2800 Switch that has been
designated in the above process.
4. Click <OK> to start telnet client. There will be pop-up login interface. If
