Chapter4 Router Configuration
4-4
Purpose
Step
Check IP config
file information
1. Use command of disable to quit back to regular user view or use
command of configure to access global configuration view, or no
command executed to remain in current privilege user view;
2. Use command of show ip config to display IP config file information;
3. Done.
Check route
information
1. Use command of disable to quit back to regular user view or use
command of configure to access global configuration view, or no
command executed to remain in current privilege user view;
2. Use command of show ip route or show ip route ip-address to
display routing information;
3. Done.
Check IPv4/IPv6
statistic information
of routing table
1. Use command of disable to quit back to regular user view or use
command of configure to access global configuration view, or no
command executed to remain in current privilege user view;
2. Use command of show { ip | ipv6} routing-table statistic to display
IPv4/IPv6 statistic information of routing table;
3. Done.
Check IPv6
interface information
1. Use command of disable to quit back to regular user view or use
command of configure to access global configuration view or use
command of interface fastethernet interface-number to access interface
configuration view;
2. Use command of show ipv6 route to display IPv6 interface
information;
3. Done.
Check summary
routing information
1. Use command of disable to quit back to regular user view or use
command of configure to access global configuration view, or no
command executed to remain in current privilege user view;
2. Use command of show ip route summary to display summary
routing information;
3. Done.
Appended List:
Parameter
Description
Value
ip-address
Destination IP address
Dotted decimal form, e.g.,
(A.B.C.D, where A~D is decimal
number from 0~255).
