Chapter4 Router Configuration
3-12
Procedure
According to the different purposes, execute corresponding step. Please refer to the
following table.
Objective
Step
Configure the
user defined
option value of
DHCP
1. Use command of configure to enter the Global Configuration View;
2. Use command of dhcp pool pool-number to enter the DHCP pool
Configuration View;
3. Use command of dhcp option option1-range ip-address ip-address or
use command of dhcp option option2-range ascii ascii-string or use
command of dhcp option option3-range hex hex-string to configure the
user defined option value of DHCP;
4. Done.
Configure the
hex value of
option212
1. Use command of configure to enter the Global Configuration View;
2. Use command of dhcp pool pool-number to enter the DHCP pool
Configuration View;
3. Use command of dhcp option 6rd ipv4 prefix-len len-range prefix
ipv6-address/MASK br ivp4-address to configure the hex value of
option212;
4. Done.
Configure the
sub-option
attribute value of
DHCP user
defined option
1. Use command of configure to enter the Global Configuration View;
2. Use command of dhcp pool pool-number to enter the DHCP pool
Configuration View;
3. Use command of dhcp option option-range sub-option sub-option
ip-address ip-address or use command of dhcp option option-range sub-
option sub-option ascii ascii-string or use command of dhcp option
option-range sub-option sub-option hex hex-string to configure the sub-
option attribute value of DHCP user defined option;
4. Done.
Appendix List:
Parameter
Description
Value
option1-range
option range
integer with range of 2-254
option2-range
option range
integer with range of 2-254
option3-range
option range
integer with range of 2-254
ip-address
designate option60 to be IP
address type
dotted decimal
ascii-string
designate option60 to be ASCII
character string type
character string, length to be
1~255
hex-string
designate option60 to be hex type
the inputted character string
