Chapter4 Router Configuration
4-3
Purpose
Step
Parameter Description
3. Done.
Appended List:
Parameter
Description
Value
ip-address
Destination IP address
Dotted decimal form, e.g., (A.B.C.D,
where A~D is decimal number from
0~255).
mask-address
Mask of destination IP address
Dotted decimal form, e.g., (A.B.C.D,
where A~D is decimal number from
0~255).
nexthop-address
Designated next hop IP
address of the route
Dotted decimal form, e.g., (A.B.C.D,
where A~D is decimal number from
0~255).
NAME
Route name defined to a
certain route
-
metric <0-255>
Route metric value
Integer form with range of 0~255.
ipv6-address
Destination IPv6 address
Pure binary numbers indication: 128
0s and 1s with 16 bits each group
and 8 group in total
mask- length
Mask length of destination IP
address
Integer form with range of 0~128.
ipv6-
nexthop-address
Designated next hop IPv6
address of the rout
Dotted decimal form, e.g., (A.B.C.D,
where A~D is decimal number from
0~255).
VLAN ID
VLAN name
Integer form with range of 1~4094.
hop-limit number
Hop limit of IPv6
Integer form with range of 0~255.
4.2.3 Maintenance and Debug
Purpose
The operation in this section is for situation when static route works abnormal and
requires function check, debug and defection orientation.
Process
According to the different purposes, execute corresponding step. Please refer to the
following table.
